Description

JU-2000E type Rigs (7 New Build Units Available: x1 Fully Commissioned, x3 Partially Commissioned & x3 Under Construction).
The JU-2000E is a high-spec jack-up rig designed for moderate harsh environments, capable of drilling in water depths up to 400 feet and to a maximum drilling depth of 35,000 feet. With dimensions of 70.358m x 76m, it features a cantilever envelope of 75ft aft and can accommodate up to 150 personnel. Powered by 6 x CAT 3516 CHD engines totaling 9618 kW, it includes a NOV TDS 1000A top drive, 5236HP drawworks, and a mud system rated for 7.5k psi. This rig meets ABS classification and is outfitted with a helideck compliant with CAP437 standards.

DSJ400 Jack-Up Drilling Rig (1 New Built Unit Available/ Fully Commissioned/ Ready for delivery globally).
The DSJ400 Jack-Up Drilling Rig is a 2022-built, self-elevating cantilever-type unit with an operating water depth capability of 400 feet, designed for moderate to harsh environments. It features state-of-the-art drilling equipment with a 2000 kips hook load, capable of drilling up to 35,000 feet. The rig provides accommodation for 150 personnel and offers enhanced safety, reliability, and operational flexibility, with a cantilever reach of 80 feet and large variable load capacities. Its ABS-classed hull, modified triangular in shape, ensures optimal performance, while the electric rack and pinion jacking system allows for efficient operation.

R550D Jack-Up Drilling Rig (1 New Built Unit Available in Operating Condition, currently drilling in China territory since 2022).
This is 400′ Ft. Jack-Up Drilling with the following brief specifications:

* High-capacity, extended reach Cantilever Rig, rated for 3,500 Kips (1,587 mt) combined drilling load with extended reach to 80 Ft. (24.4 m) aft of transom.
* Operating Variable Deck Load 11,000 Kips (4,989 mt).
* Active/ reserve mud pits 4,220 barrel (671 m3).
* Three mud pumps, each 2,220 HP (1,641 KW) TSC or equivalent.
* Drill floor/ cantilever, configured for off-line stand building with Iron Roughnecks.
* Living Quarters for 150-plus, with up to 11 office/ conference/ training rooms; configured to suit Client needs.
* Utilities and drains configured for Zero Discharge.
* Base design for closed loop or air cooling of all equipment.
* High-speed preload system for minimized mobilization time.
* Superior jacking capacity with 54 pinions allows jacking with full preload of 70,000 Kips (31,746 mt), in addition to normal jacking of 54,000 Kips (24,490 mt).
* Rated Drilling Depth Capability: 30,000 Ft. (9,144 m).

CJ46-X100-D (2 Operational Units Available for Delivery globally, Currently both Rigs are working in UAE since 2021).
CJ46-X100-D is a three-legged cantilever jack-up drilling unit designed for operations in water depths up to 114.3 meters (375 feet). It features a 21.33-meter (70-foot) cantilever with a load capacity of 1,500 kips, a high-capacity jacking system with 18 pinions per leg, and a customizable platform. The unit is equipped with powerful drilling equipment, including a 9,144-meter (30,000-foot) drilling depth capacity and advanced storage capabilities for fuel, potable water, and mud, making it highly versatile for offshore drilling in harsh environments.

Specifications

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A Buyer should instruct his agents, or his surveyors, to verify such details as per Buyer desires (project plans/scopes of work) are validated.

This vessel is offered subject to availability, price change, or withdrawal without notice.
