Description

GENERAL
Vessel Type: Deck Cargo Barge
Year Built: 2025
Class: ABS

PRINCIPAL DIMENSIONS
Length Overall: 91.50 m
Breadth Moulded: 30.48 m
Depth Moulded: 6.10 m
Designed Draft: 4.80 m

CARGO CAPACITY / DECK PARTICULARS
Deadweight: 10,000 t
Deck Loading: 15 t/m²
Deck Surface: Approx. 150 mm thick concrete
Deck Plate: 16 mm thick
Side Wall: 3.0 m
Side Shell: 12 mm thick
Bottom Shell: 14 mm thick

TOWING / MOORING / FITTINGS
Towing Brackets: 12” heavy duty
Towing Brackets: 4 nos. 60 t SWL at port & starboard, forward & aft
Towing Brackets: 1 no. 60 t SWL at forward centre
Manholes: 600 x 400 mm with studs for each compartment

ANCHOR / WINCH EQUIPMENT
Anchor / Wire Length: Yes – 120 m
Recovery Winch: Yes
Anchor Winch: Yes

ACCESS / FENDERS / NAVIGATION
Embarkation Ladder: 6 nos. — 3 port & 3 starboard
Tyre Fenders & Lugs: 42 nos. fenders with GI chain
Navigation Lights: One set, solar powered
LOA 91.5 m
Beam 30.48 m
Draft 4.8 m

Built in year 2025
Class : American Bureau of Shipping

Deadweight : 10,000 metric tonnes
